400 series Vario freezer 212.5 x 60.3 cm soft close flat hingeRF463505
Replacement for
RF463301AU
1 / 18
400 series Vario freezer 212.5 x 60.3 cm soft close flat hingeRF463505
Replacement for
RF463301AU
Find a local Dealer
Technical Overview
Energy Stars
3.0
bigbox
No
Home Connect
Yes
Highlights
Special Features
The opening assistance for handle and handleless options reveals a stainless steel interior with glare-free lighting and discreet shelving rails, movable door racks.
Opening assist for door with two options
Glare-Free LED Light Spots
Integrated ice maker
Specifications
Stainless steel interior with solid anthracite aluminium elements
Brilliant LED light spots with warm white, glare-free light (3500 K).
Opening assist for door with two options:
1. Push-to-open function for integration into handleless furniture front 2. Pull-to-open function to facilitate opening the door using a handle
The drawers in the RC and RF models are positioned at the same height. With side-by-side installation, the glass shelves can be aligned on the same level
Flat stainless steel inner door, full-length
Proximity sensor for ice and water dispenser
Illuminated dispenser for ice cubes, crushed ice and chilled water
TFT touch display
TFT touch display operation.
Clear text display.
Touch key operation for ice and water dispenser.
Dynamic cold air distribution.
Automatic defrosting with defrost water evaporation.
Rest mode certified by Star-K.
When rest mode is active, the appliance can only be opened using a handle.
Open-door and malfunction alarm.
Total volume 304 l .
No-frost technology with fast freezing at -30 °C.
Temperature adjustable from -14 °C to -24 °C.
Freezing capacity 14 kg/24 h.
Storage time after a malfunction 10 h.
2 fully extendable drawers with transparent front.
3 safety glass shelves, white glass, 2 of which are individually height adjustable.
Warm white LED lighting.
Proximity sensor for automatic activation of light and touch keys for ice and water dispenser.
Integrated, with fixed inlet water connection.
Particle filter for water inlet, integrated in ventilation grill area.
Can be switched off.
Ice cube production approx. 1.4 kg/24 h.
Ice cubes and crushed ice.
Removable ice storage container with approx. 3.2 kg capacity.
Ice water supply approx. 1.5 litres.
3 stars.
Energy consumption 313 kWh/year.
Noise level 38 dB (re 1 pW).
Flat hinge.
Door opening angle of 115°, fixable at 90°.
For an installation with a door opening angle of 90°, the drawers have a restricted access.
Max. door panel weight 67 kg.
Shut-off valve for water connection must be planned next to the appliance and always be accessible.
If the water pressure exceeds 0.8 MPa (8 bar), connect pressure relief valve between water tap and hose set.
Total connected load 0.300 KW.
Connecting cable 3.0 m, detachable.
Water inlet.
Supply hose 2.9 m with 3/4 " connection.
Water pressure 2 to 8 bar.
